The SignMe Egyptian ID OCR API returns Arabic text exactly as printed on the document — UTF-8 encoded, byte-perfect. Displaying it is a different problem. RTL direction, bidirectional Unicode, font selection, and framework-specific quirks trip up even experienced developers. This guide fixes all of it, with copy-paste code for web, mobile, and backend.

Quick Answer

Arabic text from an OCR API is valid UTF-8 — rendering problems are always caused by the UI, not the API. Fix them with five rules:

Add dir="rtl" and lang="ar" to every element containing Arabic text
Set unicode-bidi: embed in CSS to prevent a parent LTR container from overriding direction
Load an Arabic font: Cairo, Tajawal, or Amiri via Google Fonts
For mixed Arabic/English content, wrap each part in its own element with the correct direction
Never sort Arabic strings by byte order — use locale-aware collation (localeCompare('ar') in JS, CultureInfo("ar") in .NET)

Why Arabic Text Needs Special Handling

Arabic is a right-to-left script. When a browser, mobile renderer, or PDF engine encounters Arabic characters without explicit direction instructions, it falls back to its own heuristics — which frequently produce wrong results, especially in mixed content (an Arabic name next to a national ID number, for example).

Three distinct problems cause garbled Arabic output, and they compound each other:

↔️

RTL Direction

Without dir="rtl", Arabic words appear in the correct Unicode code-point order, but the line flows left-to-right — so the sentence reads backwards.

🔤

Unicode Bidi

Mixed RTL + LTR content (Arabic name + English ID number) requires explicit bidi isolation, or numbers and punctuation reorder unpredictably within the line.

🔡

Font Support

Not every font includes the Arabic Unicode block (U+0600–U+06FF). Without a suitable font, Arabic glyphs render as empty boxes or question marks.

All three have clear, well-supported fixes. The sections below give you the exact code for each platform.

Web: HTML and CSS

The minimum correct markup for any Arabic string received from the API is:

HTML

<!-- Minimum: direction + language on the element -->
<span lang="ar" dir="rtl">محمد أحمد السيد</span>

<!-- Mixed content: isolate each part in its own element -->
<div class="identity-row">
  <span lang="ar" dir="rtl" class="arabic-name">محمد أحمد السيد</span>
  <span class="id-number">29901011234567</span>
</div>

Pair the markup with a single reusable CSS class:

CSS

/* Load from Google Fonts — add to your <head> */
@import url('https://fonts.googleapis.com/css2?family=Cairo:wght@400;600;700&display=swap');

.arabic-text {
  font-family: 'Cairo', 'Tajawal', 'Amiri', Arabic, sans-serif;
  direction: rtl;
  text-align: right;
  unicode-bidi: embed;   /* prevents parent LTR context from overriding */
}

/* Use isolate when Arabic and LTR content share the same line */
.arabic-isolated {
  unicode-bidi: isolate;
}

Font priority: use Cairo for modern product UIs (it's what this site uses), Tajawal for compact tables and dashboards, and Amiri for formal or legal documents. Always include Arabic, sans-serif as a system fallback in case the web font fails to load.

Page-Level vs Element-Level Direction

If your entire UI is Arabic-first (an HR portal, a government app), set direction on the root element and override LTR for numeric fields. For mixed apps (English UI, Arabic data values), set direction per-element only.

HTML

<!-- Arabic-first app: set RTL at root -->
<html lang="ar" dir="rtl">
  <!-- override specific elements back to LTR -->
  <span dir="ltr" class="id-number">29901011234567</span>
</html>

<!-- Mixed app: set RTL only on the data cell -->
<td>
  <span lang="ar" dir="rtl" class="arabic-text">
    @customer.FullName   <!-- Blazor -->
    {customer.fullName}   {/* React / Vue */}
  </span>
</td>

Two side-by-side UI cards: Arabic name rendered incorrectly without dir=rtl versus correctly with dir=rtl and Cairo font — Left: Arabic name without direction attributes — the line flows LTR and reads backwards. Right: same data with dir="rtl" and Cairo font — correct.

JavaScript and Frontend Frameworks

When rendering API data dynamically, detect whether a field contains Arabic before applying direction. The SignMe API returns both full_name (Arabic) and full_name_en (transliterated English) — your UI may need to handle both.

JavaScript

// Detect Arabic script — Unicode block U+0600–U+06FF
function isArabic(str) {
  return /[؀-ۿ]/.test(str);
}

// Apply direction to any DOM element
function renderLocalizedText(el, text) {
  el.textContent  = text;
  el.dir          = isArabic(text) ? 'rtl' : 'ltr';
  el.lang         = isArabic(text) ? 'ar'  : 'en';
  el.classList.toggle('arabic-text', isArabic(text));
}

// Usage with a SignMe API response
fetch('https://api.signme.it/ocr', {
  method: 'POST',
  body: formData,
  headers: { 'x-api-key': apiKey }
})
  .then(r => r.json())
  .then(({ data }) => {
    renderLocalizedText(document.getElementById('customer-name'), data.full_name);
    renderLocalizedText(document.getElementById('customer-address'), data.address);
  });

React

JSX (React)

// ArabicText.jsx — reusable component for any Arabic OCR field
function ArabicText({ text, className = '' }) {
  const arabic = /[؀-ۿ]/.test(text ?? '');
  return (
    <span
      lang={arabic ? 'ar' : 'en'}
      dir={arabic ? 'rtl' : 'ltr'}
      className={`${arabic ? 'arabic-text' : ''} ${className}`.trim()}
    >
      {text}
    </span>
  );
}

// Usage in a KYC review card
function CustomerCard({ data }) {
  return (
    <div className="kyc-card">
      <ArabicText text={data.full_name} />
      <ArabicText text={data.address} />
      <span className="id-number">{data.national_id}</span>
    </div>
  );
}

Vue 3

<!-- ArabicText.vue -->
<template>
  <span
    :lang="isArabic ? 'ar' : 'en'"
    :dir="isArabic ? 'rtl' : 'ltr'"
    :class="{ 'arabic-text': isArabic }"
  >{{ text }}</span>
</template>

<script setup>
import { computed } from 'vue';
const props = defineProps({ text: String });
const isArabic = computed(() => /[؀-ۿ]/.test(props.text ?? ''));
</script>

Mobile Apps

React Native

React Native respects writingDirection in the Text style prop. Set it explicitly — do not rely on automatic detection, which varies by platform version.

React Native

import { Text, StyleSheet } from 'react-native';

const styles = StyleSheet.create({
  arabicName: {
    writingDirection: 'rtl',
    textAlign: 'right',
    fontFamily: 'Cairo-Regular',  // must be bundled in assets/fonts/
    fontSize: 16,
    color: '#1E293B',
  },
});

function ArabicName({ name }) {
  return <Text style={styles.arabicName}>{name}</Text>;
}

Flutter

Dart (Flutter)

// pubspec.yaml: add Cairo.ttf under flutter > fonts > assets
Text(
  customerName,
  textDirection: TextDirection.rtl,
  textAlign: TextAlign.right,
  style: const TextStyle(
    fontFamily: 'Cairo',
    fontSize: 16,
  ),
)

iOS (Swift)

UIKit reads RTL from semanticContentAttribute. SwiftUI uses .environment(\.layoutDirection, .rightToLeft) on the containing view.

Swift (UIKit)

let label = UILabel()
label.text                    = customer.fullName   // Arabic string from SignMe API
label.semanticContentAttribute = .forceRightToLeft
label.textAlignment            = .right
label.font                     = UIFont(name: "Cairo-Regular", size: 16)
                                  ?? .systemFont(ofSize: 16)

Backend: Storage, Search, and Sorting

Arabic text from the API can be stored as-is in any UTF-8 column — no transliteration, normalization, or special encoding is needed. Issues arise at search and sort time.

Database	Storage	Sorting / Collation	Search
PostgreSQL	UTF-8 text column	`lc_collate = 'ar_EG.UTF-8'`	`pg_trgm` or Arabic full-text dictionary
MySQL / MariaDB	UTF-8 text column	`utf8mb4_unicode_ci` — never `utf8mb4_bin`	Full-text index with `WITH PARSER ngram`
MongoDB	BSON string (UTF-8)	Collation: `locale: 'ar', strength: 2`	Text index with language `"none"` (Arabic stemmer limited)
Elasticsearch	text field	ICU analysis plugin	Built-in `arabic` analyzer — stemming, diacritics, ligatures

.NET / C#

System.Text.Json and Newtonsoft.Json both decode UTF-8 Arabic strings correctly out of the box. The only backend concern is sorting and comparison — always pass an Arabic CultureInfo.

using System.Globalization;

// Deserialisation — no special handling needed, UTF-8 is the default
var response = JsonSerializer.Deserialize<SignMeResponse>(json);
string arabicName = response!.Data.FullName;   // "محمد أحمد السيد"

// Locale-aware sort
var sortedCustomers = customers
    .OrderBy(c => c.FullName,
             StringComparer.Create(new CultureInfo("ar"), ignoreCase: true))
    .ToList();

// Locale-aware substring search
var ci = new CultureInfo("ar");
bool found = ci.CompareInfo.IndexOf(arabicName, searchTerm,
                                    CompareOptions.IgnoreCase) >= 0;

Python

import json

# json.loads handles UTF-8 Arabic natively — no extra decoding needed
response   = json.loads(api_response_text)
arabic_name = response["data"]["full_name"]   # correct Arabic string

# Locale-aware sort — requires PyICU: pip install PyICU
import icu
collator = icu.Collator.createInstance(icu.Locale('ar'))
names.sort(key=collator.getSortKey)

# Simple contains (Arabic has no case, so plain 'in' works for exact substring)
if search_term in arabic_name:
    print("Match found")

PDF Generation

Most PDF libraries need Arabic support configured explicitly — it is not automatic. Requirements: an embedded Arabic font, a Bidi algorithm (letters must be reordered for visual display), and Arabic letter shaping (isolated / initial / medial / final glyph forms).

Library	Language	Arabic Support	Notes
iText 7	.NET / Java	✅ Built-in	Set font to an Arabic TTF; use `TextAlignment.RIGHT` and `BaseDirection.RIGHT_TO_LEFT`
QuestPDF	.NET	⚠️ Partial	Embed Cairo or Noto Naskh Arabic; RTL layout requires explicit column ordering
ReportLab	Python	✅ Via plugins	Run through `arabic-reshaper` + `python-bidi` first — see code below
PDFKit / wkhtmltopdf	Node.js	✅ Via HTML	Render HTML with `dir="rtl"` and Arabic font; PDF inherits correctly
jsPDF	JavaScript	⚠️ Plugin	Requires `jspdf-arabic` plugin and an embedded Arabic font file

For Python PDF generation, always reshape and apply the Bidi algorithm before passing Arabic text to the rendering call:

Python

# pip install arabic-reshaper python-bidi
import arabic_reshaper
from bidi.algorithm import get_display

arabic_name = response["data"]["full_name"]

# Step 1: reshape letter forms (connects initial / medial / final glyphs)
reshaped = arabic_reshaper.reshape(arabic_name)

# Step 2: apply Unicode Bidi algorithm (reorders for visual left-to-right rendering)
display_name = get_display(reshaped)

# Now safe to pass to ReportLab, FPDF, or any pixel-based renderer
pdf.drawString(x, y, display_name)

SignMe API JSON response showing full_name and address fields with correct Arabic UTF-8 text — SignMe API JSON — all Arabic fields are valid UTF-8. The bytes are correct; apply dir and lang at the rendering layer.

Common Mistakes

1

Blaming the API for garbled output

The SignMe API always returns valid UTF-8. If Arabic looks wrong, the problem is in your UI — check dir, lang, font availability, and unicode-bidi before assuming the response is corrupt.
2

Setting dir="rtl" on a parent instead of the text element

RTL on a container without unicode-bidi: embed on the child causes mixed-content reordering. Always set dir and lang directly on the element that wraps the Arabic string.
3

Mixing an Arabic name and a national ID in one element

Displaying محمد أحمد السيد — 29901011234567 in a single un-isolated element causes the number to jump to the wrong end of the name. Wrap each segment in its own <span> with an explicit direction.
4

Sorting Arabic strings by byte order

Arabic Unicode code points do not produce a meaningful alphabetical order when sorted numerically. Use localeCompare('ar') in JavaScript, StringComparer.Create(new CultureInfo("ar"), ...) in .NET, or PyICU's Collator in Python.
5

Not embedding Arabic fonts in PDFs

PDFs that depend on system fonts display boxes or question marks on any machine without Arabic fonts installed. Always embed Cairo, Noto Naskh Arabic, or Amiri directly in the PDF file itself.
6

Skipping Arabic reshaping in Python PDF generation

Without arabic-reshaper and python-bidi, ReportLab renders each Arabic letter in its isolated form — technically the right characters, but visually broken because they do not connect. Always reshape before passing to a PDF renderer.

Use Cases

Every application built on the Egyptian National ID OCR API handles Arabic output. Rendering requirements differ by context:

KYC / digital onboarding: Show Arabic name and transliterated English name side-by-side in a verification card. Wrap each in its own element with the correct direction. The national ID number and expiry date stay LTR.
Hotel / hospitality check-in: Display Arabic name on a welcome screen or key card. A single container with dir="rtl" is sufficient for display-only contexts with no mixed content.
Government portals: Arabic-first UIs where the entire page is RTL. Set <html dir="rtl" lang="ar"> at root and add LTR overrides for numeric fields, dates, and English labels.
PDF contracts and invoices: Embed an Arabic font, run reshaper and Bidi, then render. Test on a clean machine (no Arabic system fonts) to confirm the embedded font is actually used.
Database-backed search: Use the correct Arabic collation for your engine. Index the Arabic name column separately from the full_name_en column — they serve different search audiences.

Frequently Asked Questions

Why does Arabic text appear reversed or garbled in my app?

The SignMe API returns valid UTF-8 — the problem is always in your rendering layer. Add dir="rtl" and lang="ar" to the element that wraps the Arabic string. If it still looks wrong, confirm that an Arabic-supporting font (Cairo, Tajawal, or Amiri) is loaded and applied.

Does the SignMe API return Arabic text in UTF-8?

Yes. All Arabic fields — full_name, address, governorate, religion, marital_status — are returned as UTF-8 encoded JSON strings. Standard parsers in every language handle this natively. No additional decoding step is needed.

How do I detect whether a string is Arabic in JavaScript?

Use a Unicode range regex: /[؀-ۿ]/.test(str). If true, set dir="rtl" and lang="ar" on the element. This is useful when a field might contain either Arabic or transliterated Latin text depending on the document scanned.

Which font should I use for Arabic text in a web or mobile app?

Cairo for modern UIs, Tajawal for compact tables and dashboards, Amiri for formal or legal documents. All three are free on Google Fonts. For mobile, bundle the font file in your app assets — never rely on system Arabic fonts being present on every device.

Can I search Arabic names stored from the API in my database?

Yes. Store Arabic strings in a UTF-8 column without modification. For search: PostgreSQL — use pg_trgm; MySQL — use utf8mb4_unicode_ci collation; Elasticsearch — use the built-in arabic analyzer. Never sort or filter Arabic with byte-order or Ordinal comparers — they produce wrong alphabetical ordering.

Why do Arabic letters appear disconnected in my generated PDF?

PDF libraries render Arabic letters in their isolated Unicode forms unless you apply shaping first. In Python, run the string through arabic-reshaper then python-bidi before passing it to ReportLab or FPDF. In .NET, iText 7 handles shaping internally when configured with an embedded Arabic font. Always embed the font — never rely on system fonts.
